GARMIN -GLS™ 10 Sonar Module
$669.99
-
The easy-to-install, networkable GLS 10 sonar black box allows you to see live, real-time scanning sonar. Add the LVS32 transducer model to see easy-to-interpret live scanning sonar images of structure, bait and fish swimming below and around your boat. You can also share sonar images seamlessly across multiple networked chartplotters.
LiveScope Down mode allows you to see live, easy-to-interpret scanning sonar images of structure and swimming fish in incredible detail below your boat — up to 200’ — even while your boat is stationary.
LiveScope Forward mode is an excellent tool for scouting and fishing out ahead of your cast. You’re looking at live, highly detailed and easy-to-interpret scanning sonar images of structure and fish swimming all around your boat up to 200’ even while your boat is stationary.- GLS 10 sonar module
- Power cable
- 2 meter Garmin marine network cable, small connector
- Network adapter cable
- Mounting hardware
- Documentation
-
DIMENSION - 9.6” x 5.9” x 2.6” (24.5 x 14.9 x 6.5 cm)
WEIGHT - 4.3 lbs (2.0 kg)
WATERPROOF - IPX7
TEMPERATURE RANGE - Operating: -15 C to 70 C
POWER INPUT - 10-31 V
POWER USAGE - 21 W typical, 58 W max
FUSE - 7.5 A
FREQUENCY - 530 - 1,100 kHz
TRANSMIT POWER - 500 W
MAXIMUM DEPTH - Down and Forward: 200’ (61.0 m)
GARMIN MARINE NETWORK PORTS - 1 small connector -
